`design` is a software intended for computing the geometry of all the
parallel manipulators whose workspace include a specified workspace.

The binary of this software is freely available via anonymous fpt (download here).

This software is provided "as is" without warranty of any kind. In no event shall INRIA be liable for any loss of profits, loss of business, loss of use or data, interruption of business, or for indirect, special, incidental, or consequential damages of any kind, arising from any error in this software.

Window system: X

Type: binary for Sun workstation

Size of binary: 3.65 Mo

Output: display, files, graphic output in xjpdraw format

**User's manual of design**

Version 0.2

7/21/1996

`design` is a software enabling, under certain restrictions, to determine
every parallel manipulators whose workspace include a given workspace.
This is an implementation of the algorithm described
in [2].

It is intended to be used for the Gough-type robot. The following parameters should be known:

- minimum and maximum length of the legs
- angles (see figure 1)

**Figure 1:** The known parameters

The design parameters are therefore the distance from the center of the base frame to each joint center and the distance from the center of the platform frame to the joint center . Consequently a robot is completely defined by these two parameters.

The purpose of `design` is to determine the planar region which enclose all
the values of defining a robot whose workspace will include a
desired workspace.

The following factors may be taken into account as restricting the workspace:

- leg length limits
- mechanical limit on the passive joints
- leg interference (assuming that a leg is a segment in a mathematical sense)

For the circular robot there will be only one region (obtained as the intersection of the regions determined for each link), a point in this region defining the radii of the circles, and therefore a unique robot geometry.

Note that you can compute independently the allowed regions for the legs only if you don't consider links interference.

In the current version the specified workspace is described by a set of segments on which the orientation of the platform is kept constant.

The program is invoked with three arguments

- a
*base*file in which the angles and are successively defined (in degree) - a
*length*file in which the minimum and maximum leg lengths are given - a
*trajectory*file in which the desired workspace is given

35 145 155 265 275 25 85 95 205 215 325 335

Here is an example of length file, ro.d:

30 30 30 30 30 30 40 40 40 40 40 40

and here is an example of trajectory file, traj.d:

0 0 20 0 0 0 10 10 20 0 0 0

where the start and end points of the segment are given. Then you can run the program with the following argument:

design base.d ro.d traj.d

We consider here the constraint of the leg length limits. For one link and for one trajectory the allowed zone is the intersection of two ellipses (usually drawn in black) minus a region which is the union of a set of ellipses (usually only two elements of the set are shown and drawn in red). A point in the allowed region define all the possible location of the attachment point of this leg, for this particular trajectory. If you have more than one trajectory the program will compute the intersection of the allowed regions for all the trajectories.

Furthermore if the attachment points are on the same circles the allowed region (a point in this region define the radii of the base and the mobile platform) is obtained as the intersection of the allowed regions for all the legs and for the trajectories.

The `design` window may be split in three components:

- a set of buttons on the top of the window
- a set of text input windows, vertical on the left
- the canvas where the region will be displayed

To compute a region you need first to define for which leg and for
which trajectory you want to compute the region. This is done in the
`Trajectory number` text window.
In this window you can give either:

- two numbers : define the trajectory you want to test (the first trajectory in your trajectory file has number 0). If you want to test all the trajectories use the value -1 for . is used to define the leg for which you want to determine the region (legs are numbered from 0 to 6).
- one number: this number is the trajectory number which be used to compute the region for all the legs. If this number is equal to -1 then all the trajectories will be used.

If you want to visualize the limits of the region click in the button
`Ellipsis`. Black ellipses will appear on the screen: the
intersection of these ellipses define the external boundary of the
allowed region. Then you have red ellipses (usually 2) which define
the
extremal ellipses of a set of forbidden ellipses whose union is
forbidden: the center of all the ellipses in the set is on the line
joining the center of the 2 ellipses shown on the screen.
Figure 2 show an example.

**Figure 2:** The limit ellipses. The allowed region is the
intersection of the two ellipses in thin line, minus the union of a
set of ellipses whose extremal elements are represented in dashed
lines

You can also compute directly the allowed region by clicking in the
`Polygons` button. If you have first click in the `Ellipsis`
button you will see the allowed region with an external border in
blue, and, if it exists, an internal border in
red. Figure 3 shows an example, corresponding to the
previous example, for which no internal border is present.

**Figure 3:** The allowed region of the previous example

If you want to visualize the region for all the legs it is better to do it leg by leg as if you do it directly for all legs it will be difficult to distinguish the regions.

For a circular robot you can compute the
allowed region by clicking in the `Same radii` button.
The program will display the allowed region: any point inside the
region define the radii of the base plate and of the mobile platform.

Leg length limits are not the only constraint for the workspace. The
mechanical limits of the passive points play also an important role.
For modeling the constraint on the joint at *A* we assume that the
operator is able to define a pyramid with planar faces, whose apex is
*A*. If the constraints on the joint are satisfied then the link will
lie inside the pyramid (figure 4).

**Figure 4:** An example of model of a constraint on a passive
joint located at .
If the mechanical limits of the joints are satisfied then
link is inside the volume delimited by the
pyramid.

In the current implementation only the constraint on the joint located
near the base can be taken into account. The joints pyramids are
described successively in a file. This file starts with the word `
all`. Then if there is no constraint on the joint the word `none`
should be present. Otherwise the file should contain:

number of facets (*n*)
`plan`

`plan`

`plan`

where are the Euler's angle defining a new frame
(to get this new frame we start from the reference frame, then we have a
rotation around the *z* axis of angle , then a rotation around
the new *x* axis of angle , then a rotation around the new *z*
axis of angle . These angle should be given in radian. Then we
have the number of facets of the pyramid, then on the same line a key
word `plan` followed by the Euler's angles defining the direction
of the normal to the facet. You must give as many such line as there
are facets.
In the following example we define a pyramid only for the first joint.

all 3.946457 0 0 4 plan 0 -60 plan 90 -60 plan 180 -60 plan -90 -60 none none none none noneNow you can indicate to

design base.d ro.d traj.d A.pyrIf when running the program you have not defined a pyramid file you can still introduce this constraint by given the name of the pyramid file in the

**Figure 5:** The allowed region for each link.

If you want to compute the intersection of this region (meaning that
you will consider a circular robot)
click in the `All pyramids` button.
This will display the allowed region for the constraints on all the
joints (figure 6), i.e. the definition of the radii.

**Figure 6:** The allowed region for a circular robot

Note that for a circular robot you can compute the allowed region
taking into account both the constraint on the leg length and the
pyramids by clicking in the `Constrains:pyr+ro` button, as shown
in figure 7.

**Figure 7:** An example of computation of allowable region
combining the leg lengths constraints and the mechanical limits. On
the left the allowable region for the leg lengths constraints and
mechanical limits constraints (in dashed lines) are shown. On the
right the allowable region for all these constraints is shown in thick
lines

You can also determine the forbidden region where links interference
will occur (links interference mean that the segments will have an
intersection), under the assumption that each pairs of legs *i*, *j* for which
you are checking the interference have the attachments points at the
same distance (i.e. ).
To determine the forbidden region for a pair of legs give in the
`Trajectory number` button the trajectory number and the numbers
of the two legs. Then click in the `Interference` button.
If you give only one leg number the region will describe the forbidden
region for which this leg interfere with one of the remaining legs. If
you don't give leg number then interference between every pair of legs
will be considered.

For a circular robot if you click in the `All constraints` button
after having define a trajectory the program will display the allowed
region, taking into account all the constraints:
leg length, joints limit (if you have given a pyramid file) and legs
interference.

The `Time` button will display the computation time for
determining the region. According to the number of trajectories, the
type of constraints taken into account, the discrete step for
the ellipses this time may range from a few millisecond to
many seconds.

When using the `Same radii`, `Constraints:pyr+ro`,
`All constraints` buttons the
button `Aire` will display the area of the region.

The button `Clear` may be used to clear the screen (note that the
`Ellipsis` button clear the screen before drawing the ellipses).

The `Discret` button is used to define the number of points of the
polygonal approximation of an ellipses. Indeed in the current
implementation the computation of the intersection and union of
ellipses is done by approximating them by polygons. If you decrease
the number of points the computation time will decrease but the result
may be very approximate. For a very fine computation you can increase
the number of points (the computation time
vary approximately as the square of the number of points).

The `Verify` button may be used to verify the result. The allowed
region will be sampled and for every points of this sampling
(remember that each point define a unique robot) the trajectories
will be tested using the algorithm described in [1]
(this algorithm enables to test quickly if a segment lie inside the
workspace of a robot). If the robot is able to perform all the
trajectories a green cross will appear, otherwise the cross will be
red. Due to the discretization of the ellipses some points close to
the border may be wrong.

The `Redraw` button enables to redraw the last result.

As soon as a drawing appear on the screen the button `x=.., y=..`
will display the value of for the current location of the
mouse. If you want to test a particular robot you may define its
geometry by clicking with the left mouse button at the desired
location (a small cross will appear). Then you save your robot by
giving a name in the `Robot file` button followed by a `
Return`. Another mean is to indicate in the `Robot point` button
the value of . In the generated file you will find first the
three coordinates of the 6 attachments points of the legs on the
base, then the three coordinates of the attachment points on the
mobile platform, then the 6 maximal lengths and then the 6 minimal
lengths.

When an allowed region has been computed you can save it.
The first method is to give a name in the `Result file` button. In
the generated file you will find a description of the region. The
external borders will start with `zone_permise` followed by a
number *n* which indicate the number of points of the following polygon
which describe the border. Then you will find the coordinates of the
*n* vertices of the polygon. A forbidden region will use the same
syntax except that `zone_permise` will be substituted by `
zone_interdite`.

Another method is to save the result in a format which can be read by
the graphic editor `xjpdraw`. This is done by giving a name in
the `Jpdraw file` button. This enable to output directly a
file which can be incorporated in a LaTeX document. Note that `
xjpdraw` is also available by ftp.

This program is rather computer intensive and some memory problems have appeared when computing to much region in a same session. It is usually preferable to check a few things then quit the program and start again.

One part of this program is sensitive to the scale, especially when
dealing with large dimension. If incorrect result appear you may try
to create a file called `configurateur` in the current directory
and writing a line like:

UPPER_SMALL 25which enable to change the value of a parameter inside the program (when started

The part of this program dealing with the leg length limit has been extensively tested and is pretty robust. On the contrary less efforts have been spent on the part related to joint limits and leg interference.

Version 0.1: 28/9/1995

Version 0.2: 21/7/1996 (minor bugs corrected)

**1**-
Merlet J-P.
Trajectory verification in the workspace for parallel manipulators.
*The Int. J. of Robotics Research*, 13(4):326-333, Augus 1994. **2**- Merlet J-P. Designing a parallel robot for a specific workspace. Research Report 2527, INRIA, April 1995.
