Featured Some intaglio print textures (Engravings, Etchings, etc.)

Discussion in 'Art' started by moreotherstuff, Aug 27, 2017.

  1. moreotherstuff

    moreotherstuff Izorizent

    The surface of an intaglio print is inked, then wiped clear so that ink remains only in the marks on the plate, then plate and paper are run through a press with enough force to squeeze the paper down into the marks to pick up the ink.

    Lighting and atmosphere within a print can be greatly controlled through judicious wiping of the ink from the plate.

    Prints very frequently are a combination of more than one technique.


    Burin Engraving - using a hand tool called a burin to carve lines into a metal plate. The lines are smooth and tend to be very controlled.
    Engraving .jpg


    Stipple Engraving - building an image from small dots poked onto the plate


    Mezzotint - using a tool called a roulette to churn up the entire surface of a plate, then using scrapers and burnishers to smooth the metal and bring out an image.


    Drypoint - using a needle-like stylus to scratch an image directly onto a plate. (They tend to have a wispy look.)


    Etching - covering the plate with a resist, scratching lines through the resist using a needle-like stylus and immersing the plate in acid to bite the lines. Several immersions are common with areas covered over with resist to produce degrees of tonality - lightest in the bath the shortest time, darkest the longest. Lines have a free hand appearance and are slightly ragged.


    Aquatint - covering the plate with a fine dusting of resin, then melting the resin to make it adhere. The plate is immersed in acid, which eats around the resin. Tonality can be controlled as in an etching.


    There is another intaglio technique called monotype in which ink is applied directly to the surface of an unworked plate and then run through the press to transfer the image to a piece of paper.

    Mugzinnys, dude, Hunter S. and 30 others like this.
  2. desperate_fun

    desperate_fun Irregular Member

    Interesting stuff. Thanks for taking the time to post this.

    Mugzinnys, dude, scoutshouse and 7 others like this.
  3. clutteredcloset49

    clutteredcloset49 Well-Known Member

    Appreciate you sharing the different techniques. I had no idea there were so many.

    @daveydempsey
    Maybe this should be moved and pinned to the top of the Art forum. If Bob doesn't mind.

  4. KentWhirled

    KentWhirled Well-Known Member

    Excellent info! Yes, pin it!

    Mugzinnys, dude, scoutshouse and 3 others like this.
  5. daveydempsey

    daveydempsey Moderator Moderator

  6. johnnycb09

    johnnycb09 Well-Known Member

    Got it bookmarked,good stuff! Thank you.

    Mugzinnys, dude, scoutshouse and 2 others like this.
  7. In For the old guy

    In For the old guy Active Member

    Please don't tell me those are copyrighted. They are now in the process of printing one per page.
    They will NOT be used for anything other than my own education. And not duplicated.
    Honest!!!!!!!!!!!!!!!
    Thank you. Thank you.

    Mugzinnys, dude, scoutshouse and 3 others like this.
  8. moreotherstuff

    moreotherstuff Izorizent

    All these photos are my own.

    I'm flattered that the thread has been pinned.

    Mugzinnys, dude, scoutshouse and 8 others like this.
  9. AJefferson

    AJefferson Well-Known Member

    That's pretty cool info.

    Mugzinnys, dude, scoutshouse and 2 others like this.
  10. moreotherstuff

    moreotherstuff Izorizent

    Running an intaglio print through a press is known as pulling the print.

    A note on color:

    Most frequently, color is added to an intaglio print by hand painting, usually with water color. This can be done any time after the print has been pulled, and it's not uncommon that a print be colored many years, even decades, after it came out of the press.

    There is a technique, called a la poupee, which has colored inks applied directly to the plate before the print is pulled. The inks are worked into the appropriate areas of the design with stubs of cotton fabric, called dollies or, in French, poupee.

    Mugzinnys, dude, scoutshouse and 8 others like this.
  11. antidiem

    antidiem Well-Known Member

    Excellent explanations and examples. Thanks! :cat:

    Mugzinnys, dude, scoutshouse and 3 others like this.
  12. LIbraryLady

    LIbraryLady Well-Known Member

    Quite an education.
    Many thanks.

  13. AuDragon

    AuDragon Well-Known Member

    Hi MOS. Fantastic information, thank you. Can someone explain how I bookmark this for future reference? :sorry:

    Mugzinnys, dude and scoutshouse like this.
  14. daveydempsey

    daveydempsey Moderator Moderator

    Highlight it, copy, then paste it into an email to yourself or just print it off.

    dude and scoutshouse like this.
  15. AuDragon

    AuDragon Well-Known Member

  16. janettekay

    janettekay Well-Known Member

    very interesting...thanks for posting !

    Mugzinnys, dude and scoutshouse like this.
  17. Pat P

    Pat P Well-Known Member

    This is a good site for additional info on printing processes (I think Fig posted a link to it in the past)...

    http://www.graphicsatlas.org/

    Mugzinnys, dude, scoutshouse and 3 others like this.
  18. Mo Bjornestad

    Mo Bjornestad Well-Known Member

    I have acquired a print with a cloth liner behind the print but not touching. The print image shows up on the cloth.

    Any thoughts about this piece or the liner?

    Thank you
    Mo 56CD83E8-1B8B-4570-A269-82BF887DEC36.jpeg 5DF042F8-0BD8-407E-AF1F-2BEBD7399D9F.jpeg 14B4942B-29DD-43BF-A6A0-E1058C4097AD.jpeg
